Tungsten Capillary Tube

Tungsten Capillary Tube Application:

1.Suitable for producing ion implantation parts.
2.For producing electric light source parts and electric vacuum components.
3.For producing heating elements and refractory parts in high temperature furnaces.
4.Used as electrodes in the field of rare earth metal industry.

If any questions,you are more than welcome to contact sales@grandsteeltube.com

  • Description
  • Specifications
  • Grand's Advantages
  • Inquiry

high quality pure tungsten capillary pipe:

DESCRIPTION:

OD: 1-10mm
WT: 0.3-4mm
Material: W1,W2,WAL1,WAL2
Surface Treatment: Polished, Forged, Straightening or as per customer’s requirements
Purity: ≥99.95%
Application For electron tubes,the heating elements of the high temperature furnace and so on.
Length:  According to requirements.
 Packing:  Packing in boxes,seaworthy packing.



Tungsten capillary tube Chemical Composition :

Grade
Tungsten content
Each Content of impurity elements
W1
≥99.95%
≤0.01%
W2
≥99.92%
≤0.01%
WAL1,WAL2
≥99.95%
≤0.01%



If any questions,you are more than welcome to contact sales@grandsteeltube.com







Tungsten Carbide End Mills

Tungsten Carbide Drill Bits

Tungsten Carbide Reamers

Customised Milling Cutters

Pure tungsten metal is with theoretical purity 99.95% and density 19.25g/cm3. As a high performance material, tungsten products have high melting temperature (3,422 °C, 6,192 °F), high density (19.25g/cm3), low vapor pressure (at temperatures above 1,650 °C, 3,000 °F), low thermal expansion combined with good thermal conductivity, sufficient electrical resistance and high modulus of elasticity. Whether the metal is shaped in disc or boat, or crucible, it will not change its density and high temperature resistance properties and mostly, the machining is done after sintering and/or forging. Wire cutting is using Ø0.18 molybdenum wire for the round outer circle or center hole.

If any questions,you are more than welcome to contact sales@grandsteeltube.com

1. Production of  Tantalum capillary tubes,tungsten capillary tubes,Zirconium capillary tubes since 2010.

2. Working with customers from Germany,France,Netherland,U.K.;etc since 2006.

3.  Samples can be delivered within 10 days after confirmation

4.  40 days as the production period and delivery after order confirmation.

5.  20,000 meters of Tantalum tubes,Tungsten Tubes,Zirconium Tubes in stock.

6.  Sizes can be offered from OD:1.00mmxWT:0.15mm to OD:12.7mmxWT:1.24mm

7.  Third party inspection like:TUV,BV,SGS,etc accepted

8.  Professional team assists your special tube requirements.

9.  Other related tubes can be offered with competitive prices:Tantalum tubes & pipes,Tungsten tubes& pipes,Zirconium tubes& pipes;etc

If any questions,you are more than welcome to contact sales@grandsteeltube.com
